This Is What AMD's Radeon RX 6000 "Big Navi" Looks Like
#1
Information
Quote:
[Image: KoaExvyhxDPESXygcCrYFF-970-80.jpeg.webp]

Big Navi is one big graphics card.

AMD dropped a surprise today with the first image of the [Only registered and activated users can see links Click here to register] alias [Only registered and activated users can see links Click here to register], which will give Nvidia's [Only registered and activated users can see links Click here to register] a run for its money for the [Only registered and activated users can see links Click here to register]. The chipmaker recently announced a keynote for Big Navi on October 28 at 10 a.m. PT and what better way to build up hype than to drop a small teaser before the event.

Big Navi exploits AMD's RDNA (Radeon DNA) 2 microarchitecture. If you've been following the console scene, RDNA 2 powers the GPUs that will land inside Microsoft's [Only registered and activated users can see links Click here to register] and Sony's [Only registered and activated users can see links Click here to register]. However, the next-generation Radeon RX 6000 series will show RDNA 2's true power. Bearing in mind AMD's close relationship with TSMC, the foundry should continue to be the provider for Big Navi chips for Team Red's next wave of graphics cards. It's pretty much a given that Big Navi is a product of TSMC's 7nm FinFET node and retains support for the fast PCIe 4.0 interface as well.

On an aesthetic level, the Radeon RX 6000, which is probably the reference edition, is a traditional looking three fan design. AMD opted for a black and silver theme with some red highlights this round, and the graphic card's profile reminds us a bit of Nvidia's [Only registered and activated users can see links Click here to register] shroud (but with one extra fan). Alternatively, it's like the [Only registered and activated users can see links Click here to register] but with a few more contours and a less boxy aesthetic.

[Only registered and activated users can see links Click here to register]

Remaining faithful to its informal codename, the Radeon RX 6000 looks to be a big graphics card. The graphics card features a triple-fan cooling solution, suggesting it has hefty cooling requirements. Common sense also tells us that AMD wouldn't implement a triple fan cooling solution unless it was really necessary.

The graphics card draws power through two 8-pin PCIe power connectors. The PCIe slot delivers up to 75W and each 8-pin PCIe power connector can supply up to 150W, meaning the Radeon RX 6000 could pull up to 375W. It doesn't necessarily mean that Big Navi is a power hog, though. It's just that the juice is there if the graphics card requires it.

We hopped into the map and did a quick flyby of the card. Obviously, it's not actually the card and is just an artistic representation of what it looks like in the Fortnite engine. Still, we can see that AMD has equipped the Radeon RX 6000 with one HDMI port, two DisplayPort outputs and the [Only registered and activated users can see links Click here to register] that's said to be present on certain Navi 21-based models.

Given the lack of the lightning bolt symbol, it's safe to assume that it's a normal USB-C port and not a Thunderbolt 3 interface. The first thought that comes to mind is that the port is there to accommodate USB-C monitors that are becoming ever so popular these days.

We'll find out more on the RX 6000 series and Big Navi on [Only registered and activated users can see links Click here to register]. It's slated to take on Nvidia's Ampere GPUs, including the [Only registered and activated users can see links Click here to register] that launches this week. If you want to take a look of the Radeon RX 6000 for yourself, you can access the AMD Battle Arena in Fortnite with the hub code 8651-9841-1639.
...
